Multilevels Q235B Steel Medium Duty Warehouse Storage Racks
Specifications:
About racking details:
1. Size L500-2500mm * D: 600-1300mm*H: 2000-10000mm(special sizes
also avaiable to
specific storage needs)
2. Loading capacity:150-300kg/level
3. Upright section:55*45mm,80*60mm, 90*60mm, 100*60mm, 88*68mm,
100*68mm, 110*68mm,
120*68mm, etc
4. Box beams section: 80*45mm, 90*45mm, 100*45mm, 110*45mm,
120*45mm, 130*45mm,
140*45mm, etc.
Medium duty shelf rack, comes with upright frame, beam, steel plate
or wood plate, loading capacity from 300kg to 500kg per level,
maximum height 4m normally, manual picking as common option or with
ladder works;
it is popular to warehouse storage system . Special work for carton
and box in different size, loose products, not heavy and flexible
to take or stock.
shelf can be adjusted each 75mm hole pattern, adapted to different
height requirement; Constructed by excellent cold rolled steel
element technology, surface proceed with zinc or phosphorous coated
in static powder and high temperature treatment, endurance with
antiseptic ability.
1. Height between layers is adjustable according to goods size.
2. Various vertical separating plate and mesh can be laid between
horizontal beams.
3. It is an ideal for a wide variety of applications high density
storage of small parts, heavy items, large and bulky items, and odd
shaped or awkward items
4. It has special design, proper structure, and is easy for
installing and dismantling without
any screw thread connector.
The standard size(mm) | Layers | Loading capacity | Upright(mm) | Beam(mm) | Thickness of board(mm) |
L2000*D600*H2000 | 4 | 300-500kg | 55*45*1.5 | 80*40*1.2 | 0.7 |
The rack that we produce can be customized according to your needs.
We will give you a quotation as soon as possible when your detaied
requirements are sent to us.
Please inform us the listed questions in your inquiry for quick
quotation:
A) The warehouse layout plans
B) The size of racking(length*width*height)
C) How many racks you want
D) How many layers for each rack that you want
E) The loading capacity of each layer
F) The price you want(EXW,FOB,CIF)
Competitive Advantage:
We are a renowned company engaged in manufacturing of a precision
engineered range of
racks.These racks provide the solution to use the existing overhead
space, thus
saves the cost of conventional building expansion. The racks
offered by us are
prefabricated and custom-designed to suit the requirements of our
clients. These are offered
to our clients at competitive prices.
